Standard Equipment

• 20 Ton hydraulic wrecker
• 58" slider boom
• Locks on slider system
• Dual 20,000lbs variable speed worm gear hydraulic winches
• 9/16" x 200' steel cable on each drum
• Air clutch release on winches
• Cable tensioners
• Direct mounted tandem hydraulic pump
• Single 5" bore x 36 3/8" cylinder for power boom elevation
• Lock & safety valve on elevation cylinder
• Two stage power boom extension
• Directional boom sheave
• Nylon slide on boom
• Dual independent hydraulic rear stiff legs
• Removable spades for stiff legs
• Lubrication fittings on all moving parts

• Dual controls on top of the deck
• Heavy duty body 96" wide
• Two toolboxes (15 Cubic Ft.)
• 110" C.A. (from cab to center of rearmost axle)
• Hi-tensile steel used for structural parts
• Sandblast + Epoxy primer paint
• Undercoating underneath the body
• Monocoque body
• Rear mounted recovery anchors
• Safety chains (2 - 3/8" x 15' grade 7)
• Door checks & hold backs
• Federal standard #108 light group
• Air plug (truck must have trailer air system)
• Electric plug
• Mud flaps

• Tandem body for 52" or 54" spread (14" longer, 124" C.A.)
• Reinforcement plate under the cab
• Reinforcement plate under the cab & bunk
• "L" shape mounting plate 5/16
• "L" shape mounting plate T1 steel 5/16
• Super medium duty axle-lift + 4 sets of brackets + tie down chains
• Heavy duty axle-lift + 4 sets of forks + tie down chains
• Tunnel toolbox 24" or 28" or 32" or 36" or 40" or 44" or 48" single door
• Tunnel toolbox 48" or 52" or 56" or 60" or 64" or 68" or 72" double door
• Pressure gauges
• Battery box inside the tunnel toolbox
• Work lights in toolboxes
• Light pylon

• Aluminum cover inside the light pylon
• Winch covers
• Aluminum checker plate on top of tunnel toolbox
• Aluminum checker plate on rear steps
• 2 Work lights under the bumper
• Stainless package
• Stainless on boom
• Stainless on mast
• Stainless on light pylon
• Stainless on bottom of body
• Stainless on winch covers
• Stainless on top of body's sides
• One-color paint (acrylic enamel)
• One-color paint (IMRON)
• Installation (includes PTO)
